Sterling Ropes are
designed to provide you the best protection possible. All
UIAA Laboratory tests demonstrate the low stretch of Sterling Dynamic under an 80kg load. Low elongation is critical to preventing cratering on the rock below.
To inhibit the absorption of moisture, all Sterling Static and Dynamic cores are made with SeaGard®, a proprietary Allied Signal yarn finish. This finish is an integral part of the manufacturing process and serves to protect the yarn during the braiding and handling operations. SeaGard® also helps in maintaining the strength of your rope in wet climbing or rescue operations. All Sterling Ropes are temperature balanced. This means that the cores and the covers have been similarly heat treated to insure even stretch characteristics.
Fire Rescue Ropes
Highest quality
tag lines and personal escape ropes
• RIT 900™, RIT 500™,
RIT Response and FireTech32™ were developed specifically for overcoming extreme
heat, fire ground obstacles, and poor visibility when searching for and
rescuing trapped firefighters or civilians.
• Sterling Rope RIT
Lines and escape ropes utilize aramid fibers which are critical when working in
situations where exposure to high heat may occur.
•
RIT-900
The RIT 900 is a 6.8mm hollow braid construction search line.
· MBS of 4,200lbs
· Heat resistant to 932° Fahrenheit
· Compact, supple, easy to knot, and extremely durable
· Easier to handle than webbing with gloved hands
· High resistance abrasion, cuts, and chemicals such as acids and alkalis
· Great for primary or personal search lines
· Optimal tagline used in conjunction with Thermal Imaging Cameras
Additional Information
|
Elongation at 10% MBS |
4.00% |
|
MBS lbs (kN) |
4,200 (18.7) |
|
Safe Working Load |
420 lbs |
|
Weight (lbs/100') |
1.9 |
RIT-500
RIT 500 is an 8mm (5/16”) personal escape rope with an aramid sheath and nylon core.
The balance of this construction ensures the rope will stay round through gear and compact to carry
· Certified to NFPA 1983, 2006 edition - Escape Rope
· MBS of 5,486 lbs
· Heat resistant sheath to 932 degree Fahrenheit
· Firm sheath and core construction helps keep dirt and other debris out of rope
· High resistance to abrasion, cuts and chemicals, especially acids and alkalis
Additional Information
|
A CE0120 certified product |
Yes |
|
A NFPA1983,2006 certified product |
Yes |
|
Elongation at 10% MBS |
6.10% |
|
MBS lbs (kN) |
5,486 (24.4) |
|
Safe Working Load |
548 lbs |
|
Weight (lbs/100') |
3.2 |
EscapeTech
EscapeTech is a 7.5mm escape rope that has a Technora sheath and nylon core construction.
· Certified to NFPA 1983, 2006 edition - Escape Rope
· MBS of 3,912 lbs
· Heat Resistant sheath to 932° F
· Technora sheath offers the best heat resistance for repeated exposures to high temperatures
· Nylon core provides a small amount of elongation when a bailout is needed
· Designed to yield a soft flexible hand for compact storage
· Round construction is easy to handle and locate with gloved hands
· Technora provides the highest level of abrasion and cut-resistance compared to other high tenacity fibers
Additional Information
|
A CE0120 certified product |
Yes |
|
A NFPA1983,2006 certified product |
Yes |
|
Elongation at 10% MBS |
5.80% |
|
MBS lbs (kN) |
3,912 (17.4) |
|
Safe Working Load |
391 lbs |
|
Weight (lbs/100') |
2.6 |
8mm (5/16”) Personal Escape Rope
Compact and lightweight Personal Escape Rope (PER) rope
· Made with 100% nylon operation
· Certified to NFPA 1983, 2006 edition - Escape Rope
· MBS of 3754 lbs
· Great handling, durable, high tensile strength lifeline
· Available in solid black and OD for military / tactical
Additional Information
|
A CE0120 certified product |
Yes |
|
A NFPA1983,2006 certified product |
Yes |
|
Elongation at 10% MBS |
6.10% |
|
MBS lbs (kN) |
5,486 (24.4) |
|
Safe Working Load |
548 lbs |
|
Weight (lbs/100') |
3.2 |
8mm (5/16”) Safetyglo
Same construction as the 8mm (5/16”) PER but with a reflective tracer added to the sheath.
· Certified to NFPA 1983, 2006 edition - Escape Rope
· MBS of 3754 lbs
· Reflective yarns illuminate rope when light shines on it
· Great handling, durable, high tensile strength lifeline
Additional Information
|
A CE0120 certified product |
Yes |
|
A NFPA1983,2006 certified product |
Yes |
|
Elongation at 10% MBS |
6.10% |
|
MBS lbs (kN) |
5,486 (24.4) |
|
Safe Working Load |
548 lbs |
|
Weight (lbs/100') |
3.2 |
FireTech 32
The official rope of FDNY Personal Escape System, the FireTech 32 is a 7.5mm escape rope made with 100% Technora which will retain core strength after exposure to elevated temps and offers a longer burn through time than mixed fiber ropes.
· Certified to NFPA 1983, 2006 edition - Escape Rope
· MBS 5,756 lbs
· Heat resistant to 932° Fahrenheit
· Excellent resistance to abrasion, cuts, and chemicals such as acids and alkalis.
Note:
Additional Information
|
A CE0120 certified product |
Yes |
|
A NFPA1983,2006 certified product |
Yes |
|
Elongation at 10% MBS |
1.60% |
|
MBS lbs (kN) |
5,756 (25.6) |
|
Safe Working Load |
575 lbs |
|
Weight (lbs/100') |
3.1 |
RIT-Response
RIT Response is a 9mm search and escape rope. The diameter of this rope makes it very easy to find in low visibility conditions while the colored tracers can be used for directional bearing.
· Certified to NFPA 1983, 2006 edition - Escape Rope
· MBS of 6,970 lbs
· Heat resistant sheath to 932° Fahrenheit
· Aramid sheath with polyester core kernmantle construction
· Engineered to have a soft flexible hand for compact storage and easy deployment
· Fits in same space as most 8mm ropes
· Perfect rope for primary search lines and RIT operations
Additional Information
|
A CE0120 certified product |
Yes |
|
A NFPA1983,2006 certified product |
Yes |
|
Elongation at 10% MBS |
3.90% |
|
MBS lbs (kN) |
6,970 (31.0) |
|
Safe Working Load |
697 lbs |
|
Weight (lbs/100') |
4.2 |
Static
Ropes
SUPERSTATIC™
The static rope that revolutionized nylon static rope
design, Certified to NFPA 1983, 2001 edition
• Sterling Rope
incorporates the finest yarns, state of the art machinery, and stringent
quality control standards
• Better Braid
Technology™ is
• Higher twist levels
make rope easy to handle and deploy
• Superior abrasion
resistance
• Smooth tight sheath protects
core from dirt and allows rope to run smoothly through gear
• ThermoDynamic
Balancing™ eliminates sheath slippage
9MM MBS of 4910 lbs.
Great for anchors and taglines.
3/8” MBS of 6280 lbs.
Rated for light use/one-person loads. Also available in SafetyGlo.
7/16” MBS of 8182 lbs.
Top choice for military operations, mountain rescue, and rope access.
Multi-purpose rescue/rappel rope.
1/2” MBS of 9276 lbs.
Perfect for mainline rescue and belay line systems. Provides even more abrasion
resistance with its 41% sheath and 59% core construction. THE ROPE for
technical rescue.
HTP™ STATIC
100% High Tenacity Polyester Static Rope
• Super low elongation
• Low electrical
conductivity
• Remains supple after
extensive use
• The feel, handling,
and knotability of dynamic rope
• Naturally dry fiber
resists moisture
• Superior abrasion
resistance
• Better UV and chemical
resistance
• Better efficiency in
mechanical advantage systems
• Great compatibility
with most standard equipment
• Best rope for
highlines
• Certified to NFPA
1983, 2001 edition
9MM MBS of 5049 lbs.
Ideal for haul lines, anchor systems, and taglines.
3/8” MBS of 6350 lbs.
Ideal for light - use rescue, haul lines, anchors, and z-drag systems.
7/16” New and improved.
MBS of 7520 lbs. Durable, extremely low stretch is perfect for rope access,
rescue haul systems, and mountain rescue.
1/2” MBS of 9557 lbs.
Low elongation makes it the top choice for mainline, haul systems, and highline
use.
For rescue and safety work, climbing walls, and caving. Sterling Static is unique because of its 48-carrier sheath. “48-carrier” refers to the number of carriers/bobbins that hold yarn on the braiding machine. This sheath gives their static superior handling and durability characteristics.
|
Catalog # |
Color |
Size ”(mm) |
Weight lbs.(kg)/100’(30.5m) |
Elongation |
Tensile Strength lbs.(kg) |
|
s1101 s1106 |
White/black Black |
7/16(11) 7/16(11) |
6.0(2.7) 6.0(2.7) |
1.5% 1.5% |
8000(3629) 8000(3629) |
|
s1251 s1256 |
White/black Black |
1/2(12.5) 1/2(12.5) |
7.0(3.2) 7.0(3.2) |
1.5% 1.5% |
9250(4195) 9250(4195) |
Dynamic Ropes
Single
and double ropes used for alpine, mountain and sport climbing. Sterling
Dynamics are also offered with a dry treatment. A wet rope is cumbersome to
carry, has a lower tensile strength and has compromised knotability at
temperatures near freezing. A good dry treatment not only deals with these
issues, but also repels dirt.
|
Catalog
# |
Size
|
Weight
g/m |
|
Impact
Force |
Elongation |
Type |
|
d880 |
8.8mm |
54.2 |
11-12 |
6.5k |
8.9% |
Double |
|
d980 |
9.8mm |
69.3 |
8 |
8.9kn |
7.0% |
Single |
|
d1020 |
10.2mm |
74.0 |
7 |
7.84kn |
6.9% |
Single |
|
d1100 |
11mm |
78.9 |
9 |
7.51kn |
3.5% |
Single |
Accessory Cord
For general utility purposes. Suitable for use as chock cord or for Prusik slings. Accessory cord is not intended as a climbing, rappelling or rescue rope. Sterling Rope offers one of the widest ranges of accessory cord available in a variety of great colors and patterns.
|
Catalog # |
Size |
Tensile Strength lbs.(kg) |
|
a300 |
3mm |
----------- |
|
a400 |
4mm |
728(330) |
|
a500 |
5mm |
1135(515) |
|
a600 |
6mm |
1653(750) |
|
a700 |
7mm |
2315(1050) |
|
a800 |
8mm |
2910(1320) |
